COXO DL-300P Intraoral Scanner
Advanced Digital Dentistry with Precision, Speed and Simplicity
The COXO DL-300P Intraoral Scanner is designed to deliver outstanding accuracy, fast digital impressions, and a superior patient experience. Combining cutting-edge imaging technology with an intuitive workflow, it is the ideal solution for modern dental practices looking to embrace digital dentistry.
Developed through the collaboration between COXO and Launca Medical, a globally recognized leader in intraoral scanning technology, the DL-300P offers exceptional scanning performance, artificial intelligence features, and seamless integration into digital dental workflows.
Included Software – No Additional License Fees
The DL-300P comes with powerful scanning software included at no extra cost.
Unlike many competing systems, there are no recurring license fees or hidden charges. Users have access to all essential features required for scanning, case management, analysis, and communication with laboratories, making the system both cost-effective and easy to use.
Key Benefits
Artificial Intelligence (AI) Mode
The integrated AI automatically recognizes teeth and soft tissues during scanning, intelligently removing the tongue, lips, and oral mucosa from the digital impression. This significantly improves scan quality while reducing scanning time.
Complete Digital Scanning
The DL-300P supports a wide range of clinical applications, including:
- Full upper and lower arch scanning
- Restorative dentistry
- Implantology
- Orthodontics
- Removable prosthetics
- Tooth preparation
Ultra-High Definition 3D Models
After scanning, the software generates highly detailed true-color 3D models that accurately reproduce intraoral anatomy.
Supported export formats include:
The scanner is compatible with virtually all major CAD/CAM systems.
Advanced Occlusion Analysis
The integrated software includes comprehensive occlusion analysis tools, featuring:
- Unilateral and bilateral occlusal scanning
- 3D color occlusion mapping
- 2D cross-sectional measurements
- Occlusal data comparison
- Intelligent occlusion reconstruction that compensates for minor patient movements during scanning
Automatic Digital Reports
Generate comprehensive patient reports with a single click.
Reports can include:
- High-definition 3D models
- Intraoral photographs
- Scanner screenshots
- CBCT data
- Panoramic images
- QR Code or shareable link for easy access
This simplifies communication with both patients and dental laboratories.
Intelligent Software Features
The DL-300P software includes numerous productivity-enhancing tools:
- AI-assisted dental condition detection
- Interactive report visualization
- Electronic signature support
- Remote scanner control using the scanner itself
- Real-time scan playback for training and review
- Built-in screenshot and video recording
- Integrated learning resources and guided scanning tutorials
- Automatic margin line extraction
- Undercut detection
- Remote diagnostics and software feedback system
Cloud Platform
The integrated cloud platform enables:
- Doctor and patient data synchronization
- High-definition 3D model visualization
- Digital report management
- Secure case sharing
- One-click submission to partner dental laboratories
- Synchronization of CBCT scans and clinical photographs
AI Virtual Model Creation
Using artificial intelligence, the software automatically generates printable virtual models, ready for production with compatible 3D printers, helping to streamline laboratory workflows.
Lightweight and Ergonomic Design
Weighing only 180 g, the DL-300P provides exceptional comfort during extended scanning sessions.
Its compact ergonomic design improves handling while the autoclavable scanning tips can withstand up to 100 sterilization cycles, ensuring maximum clinical safety.
Technical Specifications
| Specification | Details |
|---|
| Dimensions | 220 × 36 × 34 mm |
| Weight | 180 g |
| Field of View | 17 × 15 mm |
| Scanning Distance | 2–18 mm |
| Accuracy | 10 μm |
| Frame Rate | 30 FPS |
| Light Source | LED |
| Export Formats | STL, PLY, OBJ |
| Standard Tip | 20 × 17 mm |
| Mini Tip | 17 × 14.5 mm |
| Autoclavable Tip | Up to 100 cycles |
| Software | Included |
System Requirements
For optimal performance, we recommend:
- Genuine Windows 11 operating system
- Software installed on the C: drive
- Fully updated Windows installation
- Latest graphics card drivers installed (NVIDIA recommended)
- Laptop connected to AC power during operation
Recommended Scanning Workflow
Full Arch Scan
- Begin scanning from the posterior lingual or palatal area.
- Continue smoothly across the occlusal surface.
- Scan the buccal side toward the incisor region.
- Move to the opposite posterior side and repeat.
- If missing data appears, simply revisit the highlighted areas and the software will automatically complete the scan.
Occlusion Scan
Two separate occlusal scans are required.
Occlusion Scan 1
- Scan one posterior side (left or right).
Occlusion Scan 2
- Scan the opposite posterior side.
During both scans, the patient must remain in centric occlusion and avoid moving the jaw.
A complete case consists of:
- Upper Arch
- Lower Arch
- Posterior Occlusion Scan 1
- Posterior Occlusion Scan 2
Scan Verification
After completing the scan, review the generated 3D model.
Areas highlighted in light green indicate regions requiring additional scanning. Simply return to these areas, and the software will automatically integrate the missing data.
Why Choose the COXO DL-300P?
- Included software with no recurring license fees
- High precision with 10 μm accuracy
- Fast 30 FPS scanning performance
- AI-powered scanning assistance
- True-color 3D digital models
- Open CAD/CAM workflow compatibility
- Integrated cloud platform
- Lightweight ergonomic design
- Autoclavable scanning tips
- Outstanding value for modern digital dentistry
The COXO DL-300P Intraoral Scanner is a complete digital impression solution that enhances clinical efficiency, improves diagnostic accuracy, and delivers a more comfortable experience for both clinicians and patients.
